| Western blot (WB): | 1:500-2000 |
| Immunohistochemistry (IHC): | 1:50-200 |
| Immunocytochemistry/Immunofluorescence (ICC/IF): | 1:50-200 |

Western blot analysis of anti-PAX6 antibody (BM4746). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human K562 whole cell lysates,
Lane 2: human 293T whole cell lysates,
Lane 3: human Jurkat whole cell lysates,
Lane 4: human Hela whole cell lysates
Lane 5: mouse RAW264.7 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-PAX6 antigen affinity purified monoclonal antibody (BM4746) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for PAX6 at approximately 49 kDa. The expected band size for PAX6 is at 47 kDa.

IHC analysis of PAX6 using anti-PAX6 antibody (BM4746) .
PAX6 was detected in a paraffin-embedded section of rat brain tissue. The tissue section was incubated with rabbit anti-PAX6 Antibody (BM4746) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

IHC analysis of PAX6 using anti-PAX6 antibody (BM4746) .
PAX6 was detected in a paraffin-embedded section of mouse brain tissue. The tissue section was incubated with rabbit anti-PAX6 Antibody (BM4746) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

Western blot analysis of anti-PAX6 antibody (BM4746). The sample well of each lane was loaded with 30 ug of sample under reducing conditions.
Lane 1: human K562 whole cell lysates,
Lane 2: human 293T whole cell lysates,
Lane 3: human Jurkat whole cell lysates,
Lane 4: human Hela whole cell lysates
Lane 5: mouse RAW264.7 whole cell lysates.
After electrophoresis, proteins were transferred to a membrane. Then the membrane was incubated with rabbit anti-PAX6 antigen affinity purified monoclonal antibody (BM4746) at a dilution of 1:1000 and probed with a goat anti-rabbit IgG-HRP secondary antibody (Catalog # BA1054). The signal is developed using ECL Plus Western Blotting Substrate (Catalog # AR1197). A specific band was detected for PAX6 at approximately 49 kDa. The expected band size for PAX6 is at 47 kDa.

IHC analysis of PAX6 using anti-PAX6 antibody (BM4746) .
PAX6 was detected in a paraffin-embedded section of rat brain tissue. The tissue section was incubated with rabbit anti-PAX6 Antibody (BM4746) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.

IHC analysis of PAX6 using anti-PAX6 antibody (BM4746) .
PAX6 was detected in a paraffin-embedded section of mouse brain tissue. The tissue section was incubated with rabbit anti-PAX6 Antibody (BM4746) at a dilution of 1:200 and developed using HRP Conjugated Rabbit IgG Super Vision Assay Kit (Catalog # SV0002) with DAB (Catalog # AR1027) as the chromogen.
